Wunderlich Extension bracket for R 1300 GS Adventure tank protection ULTIMATE

The Wunderlich ULTIMATE plus supplementary bars complement the ULTIMATE tank protection bar, providing a seamlessly integrated extra layer of protection for the flanks of the BMW R 1300 GS Adventure.

Function and Product Features

• These ULTIMATE plus supplementary bars complement the ULTIMATE tank protection bar #13215-002 and provide additional protection for the Adventure's flanks
• They act as a coupling element between the rack base and the lower tube support, ensuring added stiffness in the tube network
• The forces and moments are distributed across two additional mounting points on both the right and left sides
• The shape of the supplementary bars further aids in the elastic absorption of peak stress loads
• This additional protection increases passive safety and reduces the risk to the rider's legs in the event of a fall
• Perfect fit
• Integrated solution from a single mould
• Simple and quick assembly

Note

• The side bracket included with the supplementary bar replaces the side bracket of the tank protection bar. It connects the tank protection bar with the supplementary bar, serving as a shared side bracket for both.

Technical Data

• Material
• Protection Bars
• Precision steel tubing with high tensile strength and elongation at break, carefully handcrafted, radii precisely formed using CNC tube bending machines, and then cleanly welded. Carefully finished and powder-coated in black.
• Material
• Side Bracket

Made from aluminium, carefully finished

• Powder-coated in black

• Dimensions
• Tube diameter: 25 millimetres
• Colour
• Protection bar structure and side bracket powder-coated in black - monochromatic

Your Wunderlich Advantages

• Wunderlich premium product.
• Small series. Handcrafted.
• Wunderlich design. Functional and integrated.
• Made in Germany
• Wunderlich 60/5
• 60-day return policy - try without risk!
• 5-year warranty

The ULTIMATE plus supplementary bars fit perfectly and provide an extra layer of passive safety

Our supplementary bars made of precision steel tubing with a diameter of 25 millimetres support, reinforce, and perfect the protective effect of the ULTIMATE tank protection bar.
